Product Introduction

This small format flatbed printer adopts white ink printing, and can set flexible hard material to print two layers at a time, which helps to increase the printing effect.

Overview
Model:1530
Category:
Views: 35100
Brand:allwin cnc
Rating: 4.8 /5 based on 61 votes
Standard Price: $1230.00 / Set
Price Range: $1230.00 to $20000.00 / Set According to Configurations
Supply Ability: 150 Sets / Month In stock! From – Jinan allwin cnc machinery co.,ltd
Payment Terms: T/T,L/C
PRODUCT DESCRIPTIONS

This small format flatbed printer adopts white ink printing, and can set flexible hard material to print two layers at a time, which helps to increase the printing effect. In addition, its operation is very simple and convenient, which is very helpful for those who are not familiar with it. It is also equipped with varnish printing options to improve gloss while providing a degree of protection for the color of the ink. Its safe and convenient ink system is more conducive to smooth printing and fast online addition.

Product Feature

Our small format flatbed printer is an ideal facility to create higher print quality than traditional methods. Its nozzle can print primer directly and inkjet primer can increase adhesion. We use white ink circulation system to avoid white color in the deposition. In addition, this small format flatbed printer has strong technical support and fast response. What’s more, it has safe and reliable printing protection to ensure people are in a reliable condition while working.

Applications

● Pint on media directly, UV printer is sample&easiy to operate.

● Low power consumption

● Environment friendly

● 6 color channels can get brilliant printing results both on the dark and light media with white ink and color ink printing

● Could achieve 3d printing result, such as braille

● Height adjustable could print materials in different heights

● Sensor height detector, the machine can adjust table according to the material thickness which you input in the software.

Safe And Reliable Print Protection

The programmatic design of the UV shutter system, effective protection operation and print head sensitive nozzle protection design, to prevent damage to the print head caused by abnormal protrusions, fully enclosed system, more secure.

Product Model6090
Printing Area600mmx900mm
Printhead TechnologyDrop-On Demand Piezo Eletric
Printhead ControlPrinthead Voltage Is Software Adjustable
Printhead TypeEpson XP600/DX7 Or DX5
Printhead Number2,3
Ink CharacteristicsUV Curing Ink
Ink ReservoirsRefillable On The Fly While Printing/1000ml Per Color
LampUV LED Lamp
Color ControlICC Based Color, Curves And Density Adjustment
Printhead ArrangementC M Y K LC LM W Optional
Cleaning SystemPositive Pressure Cleaning
Guide RailTaiwan HIWIN
Working Table6-Section Vacuum Sucking Table
Print InterfaceUSB2.0
Media Thickness0-100mm, Higher Can Be Customized
Print Resolution720*360dpi, 720*720dpi, 360*1080dpi, 720*1080dpi, 720*1440dpi, 1440*1440dpi
Printing Speed15sqm/H-30sqm/H
Life Of Printed Image3 Years (Outdoor),10years (Indoor)
File FormatTIFF, JPEG, Postscript, EPS, PDF Etc.
RIP SoftwareUltraPrint/ Photoprint/ Onyx
Power Supply220V 50/ 60Hz (10%)
Operation EnvironmentTemperature 20 To 28℃, Humidity 40% To 60%
Warranty13 Months Exclude The Consumables
Small Format Flatbed Printer (2)

PLASMA CUTTER Applications

Advertising Industry: Advertising signs, logo making, decorative products, production of advertising and avariety of metal materials.

Metal Industry: For steel, Carbon Steel, Stainless steel, alloy steel, spring steel, copper plate, aluminium plate,gold, silver, Titanium and other metal plate and tube.

package and delivery for Gantry cnc plasma cutter

All of our export machinery and equipment adopt standard plywood boxes after high temperature and high pressure treatment. The boxes meet the inspection standards of the United States and the European Union; the transportation method can be transported by plane, ship, or train according to customer requirements.
We have our own long-term cooperation transportation company, which will give us more favorable prices and feasible suggestions in transportation prices, which will minimize the customer’s freight expenses, and there will never be overcharges.

package and delivery for portable cnc plasma cutter

We also have Gantry CNC plasma cutting machine with rotary device to cut metal tubes for option.

International Shipping Around the World

All of our cutting machines can be sent to all parts of the world by sea, air, international expFEDEX, UPS, etc. You are welcome to feedback your needs and we can provide you with the most timely and accurate freight quotation, as well as the most timely and reliable service
